POOL PUMP AQUAGEM INVERTER INVERMAX (2.5KW) DCX25

Aquagem Pool Pump – Ultra Quiet, Full Inverter Efficiency for Pools 90,000–150,000L

Product Description

The Aquagem InverMax DCX25 2.5kW inverter pool pump is a high capacity full inverter swimming pool pump designed for large residential and light commercial pool systems from 90 to 150m³.

It is built for pool owners and installers who need strong water movement without the constant high electricity use and noise level of a traditional single speed pump. Instead of running at full power all the time, the InverMax DCX25 uses full inverter technology to adjust pump performance according to the pool’s circulation demand.

For daily filtration, the pump can run at a lower operating level to reduce unnecessary power use and noise. When higher flow is needed, such as during backwashing, faster water turnover, high demand filtration or larger hydraulic systems, the pump can increase performance.

The DCX25 is listed with a 2.5kW power rating, 43m³/h maximum flow rate, 25.5m maximum head, and a recommended pool volume range of 90 to 150m³. It delivers a listed 40m³/h at 8m head, 38m³/h at 10m head and 24.7m³/h at 20m head, making it suitable for demanding pool circulation setups.

The InverMax combines full inverter technology, a PMSM brushless DC motor, a FOC controller and an optimised volute hydraulic system. This combination is designed to reduce energy waste, reduce turbulence, improve efficiency and lower operating noise.

The smart touch display allows users to monitor operating information and manage pump settings. The unit supports Wi-Fi operation and optional external control through supported control modules or connection methods, making it suitable for modern pool equipment rooms and smart pool control systems.

What Is the Aquagem InverMax DCX25?

The Aquagem InverMax DCX25 is a high performance 2.5kW full inverter swimming pool pump.

It circulates pool water through the filtration system, moving water from the pool through the weir, pump, filter and return lines.

It is suitable for:

• Large residential pools from 90 to 150m³
• Pools from 90,000 to 150,000 litres
• Light commercial pool filtration systems
• Larger pools requiring strong circulation
• Pool systems with higher flow demand
• Pool owners replacing compatible high power single speed pumps
• Smart pool installations
• Pool systems requiring quiet daily filtration
• Professional pump and filter installations

It does not replace the pool filter, salt chlorinator, automatic pool cleaner, robotic cleaner, chemical treatment or water testing routine.

Why Choose the Aquagem InverMax DCX25?

The InverMax DCX25 is designed for large pool systems where a smaller residential pump may not provide enough flow.

A standard single speed pump runs at one fixed speed whenever it is switched on. This can waste electricity during normal filtration because the pump operates at full output even when the pool only needs steady circulation.

The InverMax DCX25 can adjust performance according to demand. Lower operating levels can be used for everyday filtration, while higher output can be used when the system needs stronger circulation.

This can help with:

• Lower electricity use compared with running a high power single speed pump continuously
• Quieter daily operation
• Stronger flow when needed
• Better control over filtration schedules
• Reduced unnecessary motor strain
• Better comfort around the pool area
• More flexible operation for larger pool systems

Actual savings depend on pool size, plumbing design, filter size, pump settings, operating hours, water condition and electricity tariff.

Key Features and Benefits

Suitable for 90 to 150m³ Pools

The InverMax DCX25 is designed for large pools from 90,000 to 150,000 litres, making it suitable for large residential and selected light commercial applications.

2.5kW Full Inverter Motor

The 2.5kW inverter motor gives the pump the power required for higher flow filtration systems while allowing variable performance control.

43m³/h Maximum Flow Rate

The listed Qmax is 43m³/h, supporting strong water movement for larger pool systems.

25.5m Maximum Head

The listed Hmax is 25.5m, helping the pump manage systems with higher resistance when correctly installed.

Strong Flow at Common Head Levels

The DCX25 is listed at 40m³/h at 8m head, 38m³/h at 10m head and 24.7m³/h at 20m head.

InverSilence® Technology

Aquagem’s InverSilence® technology combines inverter control, hydraulic design and brushless motor technology to reduce noise and improve operating efficiency.

PMSM Brushless DC Motor

The permanent magnet synchronous motor is designed for high efficiency, smoother operation and long term durability.

FOC Controller

The field oriented control system helps the pump manage motor performance more precisely.

Volute Hydraulic System

The volute hydraulic design helps reduce turbulence and supports smoother water flow.

Smart Touch Display

The pump includes a touch screen smart display for easier operation and monitoring.

One Touch Backwash

The one touch backwash function allows the pump to run at a higher output for sand filter cleaning.

Wi-Fi Support

The DCX25 supports Wi-Fi operation for smart control where the system is correctly configured.

Optional External Control

External control is optional and may support integration with compatible pool automation systems.

Large 2.7L Filter Basket

The 2.7L basket helps hold more debris before cleaning is required.

Easy Open Lid Nut

The easy open lid nut makes pump basket access more convenient during maintenance.

75mm Union Options

The DCX25 is designed for larger plumbing connections, with 75mm union options listed.

FAQs

What is the Aquagem InverMax DCX25?

The Aquagem InverMax DCX25 is a 2.5kW full inverter pool pump designed for large residential and light commercial pool filtration systems.

What pool size is the DCX25 suitable for?

It is suitable for pools from 90 to 150m³, or approximately 90,000 to 150,000 litres.

Is the DCX25 the same as InverCaptain?

No. The DCX25 is part of the Aquagem InverMax range, not the InverCaptain range.

What is the power rating of the InverMax DCX25?

The InverMax DCX25 is listed as a 2.5kW inverter pool pump.

What voltage does the DCX25 use?

The listed voltage is 220 to 240V, 50 to 60Hz.

What is the maximum flow rate?

The listed maximum flow rate is 43m³/h.

What is the maximum head?

The listed maximum head is 25.5m.

What is the flow at 8m head?

The listed flow at 8m head is 40m³/h.

What is the flow at 10m head?

The listed flow at 10m head is 38m³/h.

What is the flow at 20m head?

The listed flow at 20m head is 24.7m³/h.

Is the Aquagem InverMax DCX25 energy efficient?

Yes. It uses full inverter technology to adjust pump performance according to demand. Actual savings depend on how the pump is installed, programmed and used.

Can it save up to 10 times more energy?

The product positioning states up to 10 times more energy saving compared with traditional single speed high power pool pumps. Actual savings depend on operating conditions and pump setup.

Is the InverMax DCX25 quiet?

Yes. The InverMax DCX25 is designed for quieter operation, with noise listed down to 46 dB(A) depending on operating speed and installation conditions.

Does it have Wi-Fi?

Yes. The DCX25 supports Wi-Fi control where correctly configured.

Does it have a smart display?

Yes. It includes a touch screen smart display.

Does it have backwash mode?

Yes. The DCX25 includes a one touch backwash function.

Is external control included?

External control is listed as optional. Confirm the required external control module or wiring setup before installation.

Is this pump suitable for a sand filter?

Yes, when the pump is correctly matched to the filter size, pool volume and plumbing system.

Can it replace an older high power pool pump?

Yes, it can replace a compatible older high power pump when professionally matched to the pool, filter and pipework.

Is this pump suitable for small pools?

No. The DCX25 is designed for larger pool systems. Smaller pools may require a smaller inverter pump model.

Does it need professional installation?

Yes. Professional installation by a qualified pool professional or electrician is recommended.

Can I install it myself?

Pool pumps involve electrical supply, plumbing, priming, valves, bonding and controller setup. Installation should be completed by a qualified installer.

Can it run dry?

No. The pump must be filled with water before starting. Running dry can damage the mechanical seal and may void warranty.

Where should the pump be installed?

Install it on a level base in a dry, well ventilated location protected from flooding, rain exposure and harsh direct sun.

Does it need ventilation?

Yes. Allow good air circulation around the pump motor and controller.

Does it replace a chlorinator?

No. It only circulates pool water. It does not sanitise the pool on its own.

Does it replace my pool cleaner?

No. It is a filtration pump, not a pool cleaner.

What warranty does the InverMax DCX25 have?

Warranty details were not supplied in the product information provided. Confirm the current South African warranty terms with the supplier before publishing.

Key Features and Benefits

• Aquagem InverMax DCX25
• 2.5kW full inverter pool pump
• Suitable for pools from 90 to 150m³
• Suitable for pools from 90,000 to 150,000 litres
• 220 to 240V, 50 to 60Hz
• 43m³/h maximum flow rate
• 25.5m maximum head
• 40m³/h flow at 8m head
• 38m³/h flow at 10m head
• 24.7m³/h flow at 20m head
• InverSilence® technology
• Down to 46 dB(A), depending on operating conditions
• Full inverter technology
• PMSM brushless DC motor
• FOC controller
• Volute hydraulic system
• Touch screen smart display
• One touch backwash
• Wi-Fi support
• Optional external control
• Large 2.7L filter basket
• Easy open lid nut
• Designed for large pool circulation systems
• Suitable for residential and light commercial use

Real World Applications / Ideal For

• Large residential swimming pools
• Pools from 90,000 to 150,000 litres
• Light commercial pool systems
• Pools with higher circulation demand
• Large sand filter systems
• Pool owners replacing compatible high power pumps
• Homes where quiet pump operation matters
• Smart pool control installations
• Pool systems requiring higher backwash flow
• Professional pool equipment installations
• South African pool owners wanting lower running costs

Technical Specifications

Installation / Usage Notes

• Install the pump close to the pool to reduce friction loss.
• Install the pump on a flat, level and stable base.
• Protect the pump from flooding, direct rain and harsh direct sun exposure.
• Ensure good ventilation around the motor and controller.
• Use correctly sized pipework for a high flow pump.
• Keep suction pipework as short and direct as possible.
• The suction line should be correctly sized for the pump’s inlet and system flow demand.
• Use suitable valves on suction and return lines for service access.
• Fill the pump with water before starting.
• Do not run the pump dry.
• Do not operate the pump with closed valves for extended periods.
• Clean the pump basket and weir basket regularly.
• Check the lid O-ring and sealing surface.
• Use lower operating settings for daily filtration where suitable.
• Use one touch backwash only when required for filter maintenance.
• Electrical connection should be completed by a qualified person.
• Confirm Wi-Fi setup and external control requirements before commissioning.

Warranty Information

Warranty information was not supplied in the product details provided for this model.

Confirm the current South African warranty terms with the supplier before publishing the final warranty statement.

Warranty may be affected by:

• Improper installation
• Improper operation
• Inappropriate use
• Tampering
• Use of non-original spare parts
• Dry running
• Flooding or water damage to electrical components
• Poor ventilation
• Incorrect electrical connection
• Operating the pump outside its intended pool system requirements

Professional installation by a qualified pool professional or electrician is recommended to protect the product, ensure correct operation and support any future warranty claim.

Conclusion

The Aquagem InverMax DCX25 2.5kW full inverter pool pump is a high performance pump for large pools from 90 to 150m³.

With full inverter control, InverSilence® technology, a PMSM brushless DC motor, smart touch display, one touch backwash, Wi-Fi support, optional external control and a listed 43m³/h maximum flow rate, it is built for demanding residential and light commercial pool systems.
